Aspen SUB-C100292 Water Cooler POU Kit

Item Features

• The POU assembly has been designed to fit on Aspen
• The operating pressure 45 PSI
• Flow capacity > 1000 ml/min at 45 PSI
• Water Inlet Pressure: Minimum 20 PSI (0.138 Mpa) Maximum 80 PSI (0.552 Mpa)
• Where pressures may exceed 80 PSI (0.552 Mpa) or if installed above the ground floor a Pressure Reducing Valve must be fitted
• Indicator will show working valve’s failure or any leak from the tubing or fittings inside the reservoir. The bottom float is designated as the primary valve with the top float acting as the safety valve. The top float stops water flow, thereby tripping and locking the indicator into the RED position
• Determine the cause of the failure before resetting the indicator switch to the GREEN position
• Customer to use an applicable 1/4″connector to be positioned between the POU tubing inlet and the water source
