Berkeley B53602S Centrifugal Pump, 230 V, 1 Phase, Cast iron/Shaft: Threaded Stainless Steel, 3600 rpm Motor

Item Features

• NPT Tapped Openings: Suction 1-1/2 in, Discharge 1-1/4 in.
• Carefully manufactured with materials best suited for water pump applications to ensure long life and dependability
• Sturdy cast iron bracket houses seal and maintains positive alignment between motor and volute case
• Volute Case: Precision machined gray cast iron with NPT tapped openings for suction and discharge. Standard discharge position is horizontal, as pictured. Volute may be rotated for vertical-up discharge
• Impeller: Enclosed multi-vane silicon bronze impeller is balanced to eliminate vibration and provide smooth, quiet operation. Impeller is threaded on motor shaft for positive alignment
• Motor Shaft: Stainless steel shaft is threaded for direct mounting of impeller. A short shaft extension to the impeller increases shaft rigidity and extends bearing life
• Motor: Heavy-duty, 1 HP, flangemounted motor designed for continuous 3600 RPM operation. Two ball bearings are permanently lubricated, eliminating the need for re-lubrication service. Open, drip-proof enclosures are standard. All models can be furnished with either singlephase (230V) or three-phase (230/460) motors. Totally enclosed fancooled motor is avail able for threephase power
