Part # 21306

MFG # M50437

CentriPro® M50437 3 Wire Motor, 5 hp, 575 VAC, 60 Hz, 3 Phase, 3450 rpm

$39.99

Item Features

  • Precision machined, one-piece, 304 stainless steel castings used for upper and lower end bells
  • Copper Class F magnet wire and major insulation for superior heat resistance
  • Stainless steel, 17-4 PH splined shaft
  • Built-in, hermetically sealed, environmentally safe capacitor
  • Built-in check valve maintains water fill needed for cooling and lubrication
  • Removable, replaceable motor lead is held in place by (2) screws for controlled compression, no danger of stripping the lead threads
  • Three-shoe Kingsbury 700 lb thrust bearing
  • Surge arrestors built-in
Amperage Rating

1899-12-30

Bearing Type

3-Shoe Thrust

Dimensions

27.7 in L

Frequency

60 Hz

Horsepower

5 hp

Material

304 Stainless Steel

Phase

3

Rotation

CCW

Service Factor

1.15

Speed

3450 rpm
