Little Giant® 2247028802G Submersible Well Motors, 3 hp, 230 V, 60 Hz, 1 Phase

Part # 135873

MFG # 2247028802G

Little Giant® 2247028802G Submersible Well Motors, 3 hp, 230 V, 60 Hz, 1 Phase

$39.99

Item Features

  • 1500 lb Thrust Rating

  • Corrosion-Resistant Construction

  • Hermetically-Sealed Windings

  • Anti-Track Self-Healing Resin System

  • Water Lubrication

  • Filter Check Valve (Water Well)

  • Pressure Equalizing Diaphragm

  • Built-in Lightning Arrestors (single-phase)

  • Removable Water-Bloc Lead installed in 60 Hz and dual frequency rated water well motors. Consult factory for additional leads

  • NEMA Pump Mounting Dimensions

Amperage Rating

13.3 A
Bearing Type

Kingsbury Thrust
Dimensions

23.2 in L
Frequency

60 Hz
Horsepower

3 hp
Insulation Class

Class B
Material

Stainless steel
Phase

1 ph
Rotation

Counterclockwise
Service Factor

1.15
